Function introduction：
1、Use the 2.4G frequency RF remote control, no need to make the remote direct to the controller,and the RF remote can controlled it across obstacles.
2、Adopt the press key and touch wheel control remote, slightly touch the color wheel can adjust the light’s brightness smoothly .
Technical Parameters
* Supply Voltage：DC12~24V
* Output：4 CMOS output
* Connection mode：common anode
* Static power consumption：<1W
* Output current： <6A/CH
* Output Power：12V:<288W, 24V:<576W
* RF frequency：2.4G
Remarks:One Remote have 4 Group, each Group can control many pieces controller,and each Group can be control separately, and 4 Group can be control together.Easy to used .

● Operation method:
1.Connect the load wire at first, following by the power wire; Please ensure short circuit can not occur between connecting wire before you turn on the power；
2.Only the power button is effective in the OFF station, press the power button for the first time then controller will enter to the last mode before turn of the controller last time (memory off function).
3、Group operate instruction: if there is A and B two piece controller receiver, first to Power the receiver A, then press the “Group 1 ON” button for five times then the led will be flash, this means receiver A is controlled by Group 1. Second to power the receiver B,press the “Group 2 ON” button for five times, than the led will be flash, this means the Receiver B is controlled by Group 2. When press the “Master ON” button, Receiver A and B are turn on at the same time, press the “Master OFF” button, Receiver A and B are turn off at the same time , A and B receiver are changing the same when press the touch color wheel . IF you want to controller receiver A/B separately, please press the “Group 1 ON” button first, than you can adjust Receiver A color temperature or turn ON/OFF receiver A . Meanwhile, Group 2/3/4 are the same.
Remarks: One remote can control 4 group of receiver at the same time ,each Group can be including several receiver, such as 40 Receiver divided into four groups On average, the remote control can control 10 pieces receiver in each group , and achieve the synchronous effect .
|
