Technical Parameters:
* Supply Voltage：DC12V~24V
* External dimension：L86*W86*H36 mm
* Package size：L112*W104*H54mm
* Net weight：128g
* Gross weight：187g
* Output：1 CMOS Open drain Output
* Connection mode：Common anode
* Static power consumption ：<1W
* Output Current：<8A(each circuit)
* Output Power：12V:<96W, 24V:<192W
|
